RGW45CC滑块、RGW45HC滑块、RGW55CC滑块、RGW55HC滑块

2025-1-6 20:37| 发布者: njhnzc| 查看: 6| 评论: 0

摘要: 型号组件尺寸(mm)滑块尺寸(mm)滑轨尺寸(mm)HH1NWBB1CC1L1LGMTT1H2H3WRHRDhdPERGW 25CC365.523.570576.5454064.597.912M89.5106.262323.611973020RGW 25HC81114.4RGW 35CC486.53310082962527912412M101213912.63430.2 ...

型号	组件尺寸 (mm)			滑块尺寸 (mm)													滑轨尺寸 (mm)
	H	H₁	N	W	B	B₁	C	C₁	L₁	L	G	M	T	T₁	H₂	H₃	W_R	H_R	D	h	d	P	E
RGW 25CC	36	5.5	23.5	70	57	6.5	45	40	64.5	97.9	12	M8	9.5	10	6.2	6	23	23.6	11	9	7	30	20
RGW 25HC									81	114.4
RGW 35CC	48	6.5	33	100	82	9	62	52	79	124	12	M10	12	13	9	12.6	34	30.2	14	12	9	40	20
RGW 35HC									106.5	151.5
RGW 45CC	60	8	37.5	120	100	10	80	60	106	153.2	12.9	M12	14	15	10	14	45	38	20	17	14	52.5	22.5
RGW 45HC									139.8	187
RGW 55CC	70	10	43.5	140	116	12	95	70	125.5	183.7	12.9	M14	16	17	12	17.5	53	44	23	20	16	60	30
RGW 55HC									173.8	232

型号	滑轨的固定螺栓尺寸 (mm)	基本动额定负荷 C(kN)	基本静额定负荷 C₀(kN)	容许静力矩			重量
型号	滑轨的固定螺栓尺寸 (mm)	基本动额定负荷 C(kN)	基本静额定负荷 C₀(kN)	M_R (kN-m)	M_P (kN-m)	M_Y (kN-m))	滑块 (kg)	滑轨 (kg/m)
RGW 25CC	M6×20	27.7	57.1	0.758	0.605	0.605	0.67	3.08
RGW 25HC	M6×20	33.9	73.4	0.975	0.991	0.991	0.86	3.08
RGW 35CC	M8×25	57.9	105.2	2.17	1.44	1.44	1.61	6.06
RGW 35HC	M8×25	73.1	142	2.93	2.6	2.6	2.21	6.06
RGW 45CC	M12×35	92.6	178.8	4.52	3.05	3.05	3.22	9.97
RGW 45HC	M12×35	116	230.9	6.33	5.47	5.47	4.41	9.97
RGW 55CC	M14×45	130.5	252	8.01	5.4	5.4	5.18	13.98
RGW 55HC	M14×45	167.8	348	11.15	10.25	10.25	7.34	13.98
