RGH25CA滑块、RGH25HA滑块、RGH35CA滑块、RGH35HA滑块

2025-1-6 20:34| 发布者: njhnzc| 查看: 4| 评论: 0

摘要: 型号组件尺寸(mm)滑块尺寸(mm)滑轨尺寸(mm)HH1NWBB1CL1LGM×lTH2H3WRHRDhdPERGH 25CA405.512.548356.53564.597.912M6×89.510.2102323.611973020RGH 25HA5081114.4RGH 35CA556.518705010507912412M8×12121619.63430 ...

型号	组件尺寸 (mm)			滑块尺寸 (mm)											滑轨尺寸 (mm)
	H	H₁	N	W	B	B₁	C	L₁	L	G	M×l	T	H₂	H₃	W_R	H_R	D	h	d	P	E
RGH 25CA	40	5.5	12.5	48	35	6.5	35	64.5	97.9	12	M6×8	9.5	10.2	10	23	23.6	11	9	7	30	20
RGH 25HA							50	81	114.4
RGH 35CA	55	6.5	18	70	50	10	50	79	124	12	M8×12	12	16	19.6	34	30.2	14	12	9	40	20
RGH 35HA							72	106.5	151.5
RGH 45CA	70	8	20.5	86	60	13	60	106	153.2	12.9	M10×17	16	20	24	45	38	20	17	14	52.5	22.5
RGH 45HA							80	139.8	187
RGH 55CA	80	10	23.5	100	75	12.5	75	125.5	183.7	12.9	M12×18	17.5	22	27.5	53	44	23	20	16	60	30
RGH 55HA							95	173.8	232

型号	滑轨的固定螺栓尺寸 (mm)	基本动额定负荷 C(kN)	基本静额定负荷 C₀(kN)	容许静力矩			重量
型号	滑轨的固定螺栓尺寸 (mm)	基本动额定负荷 C(kN)	基本静额定负荷 C₀(kN)	M_R (kN-m)	M_P (kN-m)	M_Y (kN-m))	滑块 (kg)	滑轨 (kg/m)
RGH 25CA	M6×20	27.7	57.1	0.758	0.605	0.605	0.55	3.08
RGH 25HA	M6×20	33.9	73.4	0.975	0.991	0.991	0.7	3.08
RGH 35CA	M8×25	57.9	105.2	2.17	1.44	1.44	1.43	6.06
RGH 35HA	M8×25	73.1	142	2.93	2.6	2.6	1.86	6.06
RGH 45CA	M12×35	92.6	178.8	4.52	3.05	3.05	2.97	9.97
RGH 45HA	M12×35	116	230.9	6.33	5.47	5.47	3.97	9.97
RGH 55CA	M14×45	130.5	252	8.01	5.4	5.4	4.62	13.98
RGH 55HA	M14×45	167.8	348	11.15	10.25	10.25	6.4	13.98
