UCFL200系列外球面轴承带座JIB进口品牌样本

2025-1-1 09:58| 发布者: njhnzc| 查看: 2| 评论: 0

摘要: 유니트호칭번호축지름d(mm)주 요 치 수 (mm)설치볼트호칭베 어 링하우징호칭번호중량(kgf)HJA2A1lNLA3B1S호칭번호기본정격하중C(kgf)Co(kgf)UCFL2011211390151125.5126033.33112.7M10UC2011,280650FL2040.50UCFL2021 ...

유니트호칭번호	축지름d(mm)	주 요 치 수 (mm)										설치볼트호칭	베 어 링			하우징호칭번호	중량(kgf)
		H	J	A2	A1	l	N	L	A3	B1	S		호칭번호	기본정격하중
		H	J	A2	A1	l	N	L	A3	B1	S		호칭번호	C(kgf)	Co(kgf)
UCFL201	12	113	90	15	11	25.5	12	60	33.3	31	12.7	M10	UC201	1,280	650	FL204	0.50
UCFL202	15	113	90	15	11	25.5	12	60	33.3	31	12.7	M10	UC202	1,280	650	FL204	0.48
UCFL203	17	113	90	15	11	25.5	12	60	33.3.	31	12.7	M10	UC203	1,280	650	FL204	0.47
UCFL204	20	113	90	15	11	25.5	12	60	33.3	31	12.7	M10	UC204	1,280	650	FL204	0.45
UCFL205	25	130	99	16	13	27	16	68	35.7	34	14.3	M14	UC205	1,400	730	FL205	0.64
UCFL206	30	148	117	18	13	31	16	80	40.2	38.1	15.9	M14	UC206	1,950	1,050	FL206	0.93
UCFL207	35	161	130	19	14	34	16	90	44.4	42.9	17.5	M14	UC207	2,570	1,430	FL207	1.2
UCFL208	40	175	144	21	14	36	16	100	51.2	49.2	19	M14	UC208	2,910	1,650	FL208	1.6
UCFL209	45	188	148	22	15	38	19	108	52.2	49.2	19	M16	UC209	3,200	1,850	FL209	1.9
UCFL210	50	197	157	22	15	40	19	115	54.6	51.6	19	M16	UC210	3,510	2,100	FL210	2.2
UCFL211	55	224	184	25	18	43	19	130	58.4	55.6	22.2	M16	UC211	4,330	2,660	FL211	3.3
UCFL212	60	250	202	29	18	48	23	140	68.7	65.1	25.4	M20	UC212	5,240	3,300	FL212	4.2
UCFL213	65	258	210	30	20	50	23	155	69.7	65.1	25.4	M20	UC213	5,720	3,650	FL213	5.1
UCFL214	70	265	216	31	20	54	23	160	75.4	74.6	30.2	M20	UC214	6,220	4,000	FL214	5.7
UCFL215	75	275	225	34	20	56	23	165	78.5	77.8	33.3	M20	UC215	6,740	4,400	FL215	6.4
UCFL216	80	290	233	34	20	58	25	180	83.3	82.6	33.3	M22	UC216	7,260	4,750	FL216	7.8
UCFL217	85	302	248	36	22	63	25	190	87.6	85.7	34.1	M22	UC217	8,390	5,600	FL217	9.8
UCFL218	90	320	265	40	23	68	25	205	96.3	96	39.7	M22	UC218	9,600	6,450	FL218	12.3
