UKF300系列外球面轴承带座JIB进口品牌样本

2024-12-31 10:55| 发布者: njhnzc| 查看: 9| 评论: 0

摘要: 유니트호칭번호축지름d(mm)주 요 치 수 (mm)설치볼트호칭베 어 링하우징호칭번호적용아답터중량(kgf)aeiglsZL호칭번호기본정격하중C(kgf)Co(kgf)UKF30520110801613291637.535M14UK3052,1001,090F305H23051.4UKF30625 ...

유니트호칭번호	축지름d(mm)	주 요 치 수 (mm)								설치볼트호칭	베 어 링			하우징호칭번호	적용아답터	중량(kgf)
		a	e	i	g	l	s	Z	L		호칭번호	기본정격하중
		a	e	i	g	l	s	Z	L		호칭번호	C(kgf)	Co(kgf)
UKF305	20	110	80	16	13	29	16	37.5	35	M14	UK305	2,100	1,090	F305	H2305	1.4
UKF306	25	125	95	18	15	32	16	41	38	M14	UK306	2,660	1,440	F306	H2306	1.9
UKF307	30	135	100	20	16	36	19	45.5	43	M16	UK307	3,330	1,840	F307	H2307	2.3
UKF308	35	150	112	23	17	40	19	50.5	46	M16	UK308	4,070	2,300	F308	H2308	3.1
UKF309	40	160	125	25	18	44	19	55	50	M16	UK309	4,890	2,950	F309	H2309	4.1
UKF310	45	175	132	28	19	48	23	60	55	M20	UK310	6,200	3,650	F310	H2310	5.1
UKF311	50	185	140	30	20	52	23	63.5	59	M20	UK311	7,160	4,300	F311	H2311	5.9
UKF312	55	195	150	33	22	56	23	69.5	62	M20	UK312	8,180	5,000	F312	H2312	6.8
UKF313	60	208	166	33	22	58	23	71.5	65	M20	UK313	9,270	5,750	F313	H2313	7.9
UKF315	65	236	184	39	25	66	25	81.5	73	M22	UK315	11,300	7,400	F315	H2315	11.7
UKF316	70	250	196	38	27	68	31	82.5	78	M27	UK316	12,300	8,250	F316	H2316	12.9
UKF317	75	260	204	44	27	74	31	92	82	M27	UK317	13,300	9,200	F317	H2317	15.2
UKF318	80	280	216	44	30	76	35	92	86	M30	UK318	14,300	10,200	F318	H2318	19.0
UKF319	85	290	228	59	30	94	35	111	90	M30	UK319	15,300	11,300	F319	H2319	21.9
UKF320	90	310	242	59	32	96	38	113	97	M33	UK320	17,300	13,500	F320	H2320	25.4
UKF322	100	340	266	60	35	94	41	120	105	M36	UK322	20,500	17,200	F322	H2322	35.2
UKF324	110	370	290	65	40	110	41	130.5	112	M36	UK324	20,700	17,400	F324	H2324	47.6
UKF326	115	410	320	65	45	115	41	131.5	121	M36	UK326	22,900	20,200	F326	H2326	65.3
UKF328	125	450	350	75	55	125	41	147.5	131	M36	UK328	25,300	23,200	F328	H2328	93.4
