序号 |
型号 |
代号 |
公称转矩
T
n
N.m |
外环 |
内环 |
质量
m
kg |
D(h7) |
键槽
b×t |
L1 |
d(h7) |
键槽
b×t |
L1 |
1 |
CKD12 |
CKD37×20-12 |
45 |
37 |
6×3.0 |
20 |
12 |
6×2.8 |
28 |
0.15 |
2 |
CKD15 |
CKD47×30-15 |
54 |
47 |
7×3.5 |
30 |
15 |
5×2.4 |
30 |
0.19 |
3 |
CKD17 |
CKD47×23-17 |
72 |
47 |
8×1.5 |
23 |
17 |
3×1.4 |
24 |
0.21 |
4 |
CKD20 |
CKD60×22-20 |
95 |
60 |
6×3.5 |
22 |
20 |
6×2.8 |
24 |
0.30 |
5 |
CKD25 |
CKD62×22-25 |
145 |
62 |
8×1.5 |
22 |
25 |
|
22 |
0.35 |
6 |
CKD30 |
CKD72×27-30 |
160 |
72 |
10×2.4 |
27 |
30 |
8×2.0 |
27 |
0.37 |
7 |
CKD35 |
CKD72×25-35 |
230 |
72 |
8×1.5 |
23 |
35 |
5×2.3 |
24 |
0.43 |
8 |
CKD40 |
CKD90×33-40 |
250 |
90 |
12×4.0 |
33 |
40 |
12×2.4 |
32 |
0.70 |
9 |
CKD45 |
CKD85×31-45 |
450 |
85 |
12×3.5 |
31 |
45 |
6×2.8 |
32 |
0.80 |
10 |
CKD50 |
CKD90×31-50 |
500 |
90 |
12×3.5 |
31 |
50 |
10×2.8 |
32 |
0.85 |
11 |
CKD60 |
CKD110×31-60 |
650 |
110 |
12×3.5 |
31 |
60 |
10×3.3 |
32 |
1.25 |
12 |
CKD70 |
CKD125×38-70 |
1200 |
125 |
12×3.5 |
38 |
70 |
12×3.3 |
39 |
1.90 |
13 |
CKD80 |
CKD140×38-80 |
1500 |
140 |
12×3.8 |
38 |
80 |
12×3.3 |
39 |
2.30 |
14 |
CKD90 |
CKD160×38-90 |
2000 |
160 |
12×3.5 |
38 |
90 |
12×3.3 |
39 |
3.10 |
◆CKD型相当UHF系列、德国STIEBER的ASNU系列
|
